Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable

China Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable supplier

Large Image :  Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable

Product Details:

Place of Origin: China
Brand Name: JUNPU
Certification: ROHS, CE, CCC
Model Number: GYTS 48 Core Armored Fiber Optic Cable Outdoor

Payment & Shipping Terms:

Packaging Details: wooden reel of anti-rodent 6 core optical fiber cable GYTS
Delivery Time: 1 ~ 10 Working days based on the quantity
Payment Terms: T/T
Supply Ability: 30000 Kilometer/Kilometers per Week anti-rodent 6 core optical fiber cable GYTS
Contact Now
Detailed Product Description
Application: Telecommunication,outdoor Aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise Fiber Type: G652D,OM3,G657A2,50/125,62.5/125
Number Of Conductors: ≥ 10 Fiber Count: 4 ~ 192 Core
Jacket Material: PE,LSZH Product Name: GYTS 48 Core Armored Fiber Optic Cable Outdoor
Laying Method: Aerial And Pipeline Laying Method Package: 2km/roll
Model Number: GYTS



Duct GYTS 48 Core Armored Fiber Optic Cable Outdoor Price Per Meter


Decsripttion

  • GYTS The fibers,250μmm,are position in a loose tube made of a high modulus plastic.The tube are filled with a water resistant filling compound.A steel wire,sometimes sheathed with ployethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member.
  • Tubes (and fillers) are stranded around the strength member into a compact and circular cable core.The PSP is longitudinally applied over the cable core,which is filled with filling compound to protect it from water ingress,the cable is completed with a PE sheath.

Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable

Features

  • Steel wire strength filler protect tube fiber.steel tape armored.
  • Good ultra violet radiation resistant property.
  • Good moisture-resistance.



Application

  • Mainly adopted to direct buried, duct and cable trench.



Optical Characteristics

No.

Characteristics

Parameter value

1

Tensile Strength

Short Term

1000N

Long Term

500N

2

Crush Resistance Strength (N/100mm)

Short Term

1000N

Long Term

300N

3

Min. Bending Radius (mm)

Dynamic

20D

Static

10D

4

Temperature Range

-40~+60°C


Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable

Package
Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable
Duct GYTS 48 Core Outdoor Fiber Optic Cable , CE Armored Optical Cable

We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
