Product Details
Place of Origin: China
Brand Name: JUNPU
Certification: ROHS, CE, CCC
Model Number: Fiber Drop FTTH Optic Cable
Payment & Shipping Terms
Packaging Details: 2KM /reel 2 core ftth drop cable
Delivery Time: 1 ~ 10 Working days based on the quantity
Payment Terms: T/T
Supply Ability: 1000 Kilometer/Kilometers per Week 2 Core Indoor Fiber Drop FTTH Optic Cable GJYXCH / GJYXFCH
Application: |
Telecommunication,outdoor Aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise |
Fiber Type: |
G652D/G657A1/G657A2 |
Number Of Conductors: |
2 |
Fiber Count: |
1 2 4 Core |
Jacket Material: |
LSZH |
Product Name: |
2 Core Indoor Fiber Drop FTTH Optic Cable GJYXCH / GJYXFCH |
Model Number: |
GJYXCH / GJYXFCH |
Package: |
2km/roll |
Strength Member: |
FRP Or Steel Wire |
Application: |
Telecommunication,outdoor Aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise |
Fiber Type: |
G652D/G657A1/G657A2 |
Number Of Conductors: |
2 |
Fiber Count: |
1 2 4 Core |
Jacket Material: |
LSZH |
Product Name: |
2 Core Indoor Fiber Drop FTTH Optic Cable GJYXCH / GJYXFCH |
Model Number: |
GJYXCH / GJYXFCH |
Package: |
2km/roll |
Strength Member: |
FRP Or Steel Wire |
2 Core Indoor Fiber Drop FTTH Optic Cable GJYXCH / GJYXFCH
Decsripttion
Application
Indoor cable distribution;
Adapted to core network, access network and fiber to home.
Feature
Optical Characteristics
|
Item |
Description |
|
|
Approx. Cable Diameter |
(2.0×3.0)±0.1mm |
|
|
Approx. Cable Net Weight |
11kg/km |
|
|
Strength Member |
Material |
FRP or Steel Wire |
|
Outer Diameter |
0.50±0.02mm/0.45±0.02mm |
|
|
Optical Fiber |
Type |
ITU-T G .657 Fibers |
|
Numbers |
1/2/4 |
|
|
LSZH Sheath of Cable |
Material |
LSZH |
|
Fiber Attenuation Coefficient in Cable |
dB/km(1310nm) |
≤0.4dB/km |
|
dB/km(1550nm) |
≤0.3dB/km |
|
|
Cable Type |
Tensile Strength (N) |
Crush Resistance Strength (N/100mm) |
Min. Bending Radius (mm) |
|||
|
Short Term |
Long Term |
Short Term |
Long Term |
Dynamic |
Static |
|
|
GJXFH |
80 |
40 |
1000 |
500 |
20H |
10H |
|
GJXH |
200 |
100 |
2200 |
1000 |
20H |
10H |
|
Operation Temperature:-40°C~+60°C |
||||||
