Product Details
Place of Origin: China
Brand Name: JUNPU
Certification: ROHS, CE, CCC
Model Number: Outdoor Figure 8 Core Fiber Optical Cable
Payment & Shipping Terms
Packaging Details: wooden reel of Junpu GYTC8A Figure 8 Fiber Optical Cable Self-Supporting Optic Fiber Cable Duct
Delivery Time: 1 ~ 10 Working days based on the quantity
Payment Terms: T/T
Supply Ability: 30000 Kilometer/Kilometers per Week
Application: |
Telecommunication,outdoor Aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise |
Fiber Type: |
G652D,OM3,G657A2,50/125,62.5/125 |
Number Of Conductors: |
≥ 10 |
Fiber Count: |
1-144 Core |
Jacket Material: |
PE,LSZH |
Product Name: |
Outdoor Figure 8 Core Fiber Optical Cable |
Loose Tube Material: |
PBT |
Package: |
2km/roll |
Strength Member: |
Steel Wire |
Application: |
Telecommunication,outdoor Aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise |
Fiber Type: |
G652D,OM3,G657A2,50/125,62.5/125 |
Number Of Conductors: |
≥ 10 |
Fiber Count: |
1-144 Core |
Jacket Material: |
PE,LSZH |
Product Name: |
Outdoor Figure 8 Core Fiber Optical Cable |
Loose Tube Material: |
PBT |
Package: |
2km/roll |
Strength Member: |
Steel Wire |
GYTC8A Outdoor Figure 8 Core Fiber Optical Cable Self-Supporting Optic Fiber Cable Duct
Decsripttion
Application
Optical Characteristics
|
Strength Member |
Dimension |
2.4(0.8*7)mm |
|
Material |
Steel Wire |
|
|
Outer Sheath |
Dimension |
(9.2±0.3)mm×(16.5±0.5)mm(4-24F) |
|
(9.6±0.3)mm×(16.9±0.5)mm(36F) |
||
|
(10.1±0.5)mm×(17.4±0.7)mm(48F/60F) |
||
|
(10.7±0.5)mm×(18.0±0.7)mm(72F) |
||
|
(12.2±0.5)mm×(19.5±0.7)mm(96F) |
||
|
(14.8±0.5)mm×(22.1±0.7)mm(144F) |
||
|
Material |
PE |
|
|
Color |
Black |
|
|
Fiber Attenuation Coefficient in Cable |
dB/km(1310nm) |
≤0.36dB/km |
|
dB/km(1550nm) |
≤0.22dB/km |
