Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH

Product Details

Place of Origin: China

Brand Name: JUNPU

Certification: ROHS, CE, CCC

Model Number: GYXTZW

Payment & Shipping Terms

Packaging Details: Plastic/ Carton/wooden drum/Customized

Delivery Time: 1 ~ 10 Working days based on the quantity

Payment Terms: T/T

Supply Ability: 1000 Kilometer/Kilometers per Month Junpu Outdoor F8 8 Core Singlemode G.652D Fiber Optic Cable

Get Best Price
Highlight:
Application:
Aerial, Duct
Fiber Type:
Single Mode G652D
Number Of Conductors:
≥ 10
Fiber Count:
8 Core
OEM:
Acceptable
Product Name:
GYXTZW Outdoor F8 8 Core Singlemode G.652D Fiber Optic Cable
Strength Member:
Steel Wire
Package:
1km - 6km/roll
Jacket Material:
PE Outer Sheath
Application:
Aerial, Duct
Fiber Type:
Single Mode G652D
Number Of Conductors:
≥ 10
Fiber Count:
8 Core
OEM:
Acceptable
Product Name:
GYXTZW Outdoor F8 8 Core Singlemode G.652D Fiber Optic Cable
Strength Member:
Steel Wire
Package:
1km - 6km/roll
Jacket Material:
PE Outer Sheath
Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH

Outdoor Multimode/Single Mode Fiber Optic Cable, G652D/G657A1 LSZH



Characteristics:

  • Good mechanical and temperature performance.
  • PVC outer sheath and PE inner sheath make cable have nice moisture resistance performance.
  • Crush resistance and flexibility.
  • Small cable diameter,light cable weight,easily to install.
  • We can also provide OEM service,and the packing as customer’s requirement.



    G.652 G.655 50/125μm 62.5/125μm



Attenuation(+20℃)
@850nm     ≤3.0dB/km ≤3.3dB/km
@1300nm     ≤1.0dB/km ≤1.0dB/km
@1310nm   ≤0.40dB/km
@1550nm ≤0.22dB/km ≤0.23dB/km

Bandwidth(Class A)
@850nm     ≥500MHz·km ≥200MHz·km
@1300nm     ≥1000MHz·km ≥600MHz·km
Numerical Aperture     0.200±0.015NA 0.275±0.015NA
Cable cut-off wavelength ≤1260nm ≤1450nm

Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH 0Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH 1

Application

  • Adopted to Outdoor Aerial, Duct installation



Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH 2

Package
Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH 3
Outdoor Multimode/single mode Fiber Optic Cable, G652D/G657A1 LSZH 4

We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
